Basic Information
The Digital 7 Segment Display GN001019 is a precision LCD solution designed for clear numeric visualization in electronic systems. Built on a classic segmented architecture, it provides stable and easy-to-read digit output for a wide range of embedded and industrial applications. This module is engineered for reliability, low power operation, and consistent performance in devices requiring accurate numerical representation.
Parameters:
| Character Type | Customized |
| Model | SJXDGN001019 |
| Model Size | 79.2×83×2.8mm |
| VA Size | 76.2×76mm |
|
Polarizer
|
Reflective |
|
Working Voltage
|
3.0V |
|
LCD Type
|
FSTN positive (Gray)
|
|
Drive Conditions
|
11/8 DUTY ，1/3 BIAS
|
| Working Temperature |
-20'C TO+70°C
|
|
Storage Temperature
|
-30°C TO+80°C |
Feature
- High contrast, wide-temperature operation
- Low power consumption, high anti-interference performance
- Support for multiple color combinations
- Provide a complete set of one-stop technical information and source code
- Supports customization
- Supports 1-3 day samples
- High quality and cost-effective
Key Specifications
This digital 7 segment display utilizes a structured liquid crystal segmented design optimized for numeric information presentation. It delivers sharp and well-defined digits, ensuring clear readability of measurement values, counters, and system data. The display operates at low voltage, making it suitable for energy-efficient electronics and battery-powered equipment. It is designed for ultra-low power consumption, supporting continuous operation without significant energy demand. The module maintains stable contrast performance, allowing information to remain visible under typical indoor lighting conditions. Its compact construction enables easy integration into handheld devices, industrial meters, and embedded control systems. The display ensures fast segment response, enabling real-time updates without delay or visual lag, which is essential for dynamic measurement environments.
Design Standards
The module is manufactured according to strict LCD industry standards to ensure long-term durability and consistent optical performance. High-quality liquid crystal materials are used to maintain uniform segment clarity and stable visual output throughout the product lifecycle. Circuit architecture is optimized to minimize electromagnetic interference and ensure reliable signal transmission in electronic systems. The structural design enhances resistance to mechanical stress, temperature variation, and continuous operational cycles. Each unit undergoes thorough testing to verify segment accuracy, brightness uniformity, and electrical stability. Energy-efficient design principles are applied to extend operational life and improve overall system efficiency.
Applications
The digital 7 segment display is widely used in digital meters, industrial control equipment, handheld measuring instruments, consumer electronics, and embedded systems. It is also suitable for utility monitoring devices, portable diagnostic tools, timing systems, and compact numeric interfaces requiring stable and low-power display solutions. Its combination of clarity, reliability, and efficiency makes it an effective choice for modern electronic products requiring precise numeric visualization.
Product Size
FAQ
Q: Do you provide samples?
A: Yes, samples are typically available within 1-3 days for customers to test and evaluate the module's performance and compatibility.
Q: How to customize this LCD display module?
A: The module can be customized according to customer requirements, including character display content, backlight color, shell design, and other parameters, to meet specific application needs.
Q: What applications is this module suitable for?
A: This module is suitable for applications requiring the display of large font characters and numbers, such as meters, equipment control panels, and information display systems.
Q: How is the quality of this module?
A: This module is manufactured using high-quality LCD panels and electronic components, designed to be stable and reliable, ensuring long-term stable operation and high-quality display performance.
Q: How is cost-effectiveness ensured?
A: The module is designed with streamlined production and cost control, aiming to provide a cost-effective solution while maintaining high quality and performance.
If you would like to learn more or customize the LCD display screen you need, please feel free to contact us.
