Basic Information
24x2 Graphic LCD Display SJXD2402A offers a wider two-line dot matrix interface for menus, readings, symbols, and equipment messages. It uses a 118.0×36.0×13.5 mm outline, 94.5×17.8 mm viewing area, white LED backlight, ST7066/AIP31066 controller IC, and 16PIN dual interface. Supporting 3.3V/5.0V drive voltage, wide temperature operation, low power use, and customizable configurations, it fits instruments, meters, automation panels, power devices, medical electronics, and embedded control systems.
Parameters:
| Character Type | 24×02 |
| Model | SJXD2402A |
| Model Size | 118.0×36.0×13.5 mm |
| VA Size | 94.5×17.8 mm |
|
Drive Voltage
|
5.0V/3.3V
|
|
Drive IC
|
ST7066/AIP31066
|
|
Backlight
|
white LED backlight
|
|
LCD Type
|
FSTN positive
|
|
Interface
|
16PIN dual interface
|
| Working Temperature |
-20°C - +70°C
|
|
Storage Temperature
|
-30°C - +80°C |
Feature
- High contrast, wide-temperature operation
- Low power consumption, high anti-interference performance
- Support for multiple color combinations
- Provide a complete set of one-stop technical information and source code
- Supports customization
- Supports 1-3 day samples
- High quality and cost-effective
Key Specifications
24x2 Graphic LCD Display SJXD2402A uses a 24-column, 2-line dot matrix layout for presenting extended text, numbers, symbols, menu labels, and operating data. The module has a 118.0×36.0×13.5 mm outline size and a 94.5×17.8 mm viewing area, giving compact equipment more horizontal display space. It supports 3.3V/5.0V drive voltage, ST7066/AIP31066 controller IC, white LED backlight, 16PIN dual interface, and wide-temperature operation for stable device integration.
Design Standards
24x2 Graphic LCD Display is built for projects that require clear dot matrix character output with practical panel size control. Its two-line structure helps display longer information without increasing the overall device footprint. The module supports reliable performance from -20°C to +70°C and storage from -30°C to +80°C. Low power consumption, anti-interference capability, backlight customization, color matching, technical documentation, sample support, and OEM configuration options help manufacturers adapt the display to different product designs.
Applications
24x2 Graphic LCD Display is suitable for products that need wider two-line information display, such as parameter names, test results, status messages, setting menus, and fault prompts. It can be used in industrial instruments, control panels, power devices, automation equipment, smart meters, medical electronics, household appliances, communication terminals, access systems, educational kits, and embedded controller projects. Its 24×2 format gives engineers more readable content space while keeping the display simple, economical, and easy to install.
Product Size
FAQ
Q: Do you provide samples?
A: Yes, samples are typically available within 1-3 days for customers to test and evaluate the module's performance and compatibility.
Q: How to customize this LCD display module?
A: The module can be customized according to customer requirements, including character display content, backlight color, shell design, and other parameters, to meet specific application needs.
Q: What applications is this module suitable for?
A: This module is suitable for applications requiring the display of large font characters and numbers, such as meters, equipment control panels, and information display systems.
Q: How is the quality of this module?
A: This module is manufactured using high-quality LCD panels and electronic components, designed to be stable and reliable, ensuring long-term stable operation and high-quality display performance.
Q: How is cost-effectiveness ensured?
A: The module is designed with streamlined production and cost control, aiming to provide a cost-effective solution while maintaining high quality and performance.
If you would like to learn more or customize the LCD display screen you need, please feel free to contact us.
