Basic Information
The SJXDGW013 7 Segment LCD Display Connection module is a customized segmented display solution designed to provide reliable numeric visualization and stable electrical integration for embedded electronic systems. It focuses on clear display output and simplified connection design, making it suitable for industrial equipment, control systems, and electronic instrumentation. This module is engineered to ensure accurate signal transmission and consistent display performance in various operating environments.
Parameters:
| Character Type | Customized LCD |
| Model | SJXDGW013 |
| Model Size | 100.0×53.0×2.8 mm |
| VA Size | 92.0×50.0mm |
|
Drive Voltage
|
5.0V
|
|
Backlight
|
no backlight
|
|
LCD Type
|
HTN positive
|
|
PIN
|
43 PIN
|
| Working Temperature |
-30°C - +80°C
|
|
Storage Temperature
|
-40°C - +90°C |
Feature
- High contrast, wide-temperature operation
- Low power consumption, high anti-interference performance
- Support for multiple color combinations
- Provide a complete set of one-stop technical information and source code
- Supports customization
- Supports 1-3 day samples
- High quality and cost-effective
Key Specifications
The SJXDGW013 7 Segment LCD Display Connection features a standard segmented LCD architecture optimized for numeric representation. It supports clear and stable digit display with high contrast, ensuring readability under different lighting conditions. The module is designed for low power consumption, making it suitable for battery-powered and energy-efficient devices. It provides stable electrical characteristics and reliable signal response, ensuring consistent segment activation during operation. The display is structured for easy connection and integration, reducing design complexity in electronic development. Its compact structure allows seamless embedding into various devices without requiring significant modifications. The module maintains stable performance across different environmental conditions, ensuring dependable operation in both industrial and consumer applications.
Connection Design Features
This 7 segment LCD display connection module is designed with a focus on simplified wiring and stable interface performance. It provides clearly defined connection points for efficient integration with control boards and driver circuits. The design ensures accurate signal routing to each segment, enabling precise numeric output. Its optimized connection structure reduces installation errors and improves system reliability. The module supports stable long-term operation, ensuring consistent display quality even under continuous use. It is engineered to maintain compatibility with a wide range of electronic systems, making it suitable for both standard and customized applications.
Applications
The SJXDGW013 7 Segment LCD Display Connection is widely used in digital meters, industrial controllers, measuring instruments, timers, counters, household appliances, and embedded electronic systems. It is suitable for applications requiring clear numeric display and reliable connection performance, such as monitoring devices, power meters, and control panels. It is also commonly used in OEM and ODM projects requiring customized LCD integration solutions.
Product Size
FAQ
Q: How long does it usually take to ship？
A: Generally, shipments start within 1-3 days.
Q: How to customize this LCD display module?
A: The module can be customized according to customer requirements, including character display content, backlight color, shell design, and other parameters, to meet specific application needs.
Q: What applications is this module suitable for?
A: This module is suitable for applications requiring the display of large font characters and numbers, such as meters, equipment control panels, and information display systems.
Q: How is the quality of this module?
A: This module is manufactured using high-quality LCD panels and electronic components, designed to be stable and reliable, ensuring long-term stable operation and high-quality display performance.
Q: How is cost-effectiveness ensured?
A: The module is designed with streamlined production and cost control, aiming to provide a cost-effective solution while maintaining high quality and performance.
If you would like to learn more or customize the LCD display screen you need, please feel free to contact us.
