Basic Information
The Graphic LCD Display Modules TG-12864A are compact monochrome display solutions designed for embedded systems that require clear graphical representation and reliable performance. With a 128×64 dot matrix resolution, the module is capable of displaying text, symbols, and simple graphics with high readability. It is widely used in industrial and electronic applications where stable visual output and low power consumption are essential. The module is engineered for long-term operation, offering consistent performance in both standard and demanding environments. Its efficient design ensures smooth integration into a wide range of embedded control systems.
Parameters:
| Character Type | Customized |
| Model | TG-12864A |
| Model Size | 93×70×14mm |
| VA Size | 72×40mm |
|
Display Type
|
STN Negative |
|
Viewing Angle
|
6:00/9:00/12:00 |
|
Working Temp
|
-20'C-+70°C
|
|
Storage Temp
|
-30°C-+80°C
|
| Drive Method |
1/64D;1/9B
|
|
Working Voltage
|
3.3V/5.0V |
Feature
- High contrast, wide-temperature operation
- Low power consumption, high anti-interference performance
- Support for multiple color combinations
- Provide a complete set of one-stop technical information and source code
- Supports customization
- Supports 1-3 day samples
- High quality and cost-effective
Key Specifications
This Graphic LCD Display Modules unit features a 128×64 resolution with FSTN positive display technology, providing enhanced contrast and improved viewing clarity. It supports a standard operating voltage of 5.0V, making it compatible with many embedded platforms. The module is driven by a reliable controller architecture that ensures stable data transmission and accurate graphical rendering. LED backlight technology is used to deliver uniform illumination while maintaining low energy consumption. The display is designed to operate within industrial temperature ranges, ensuring stable performance in various environmental conditions. Its compact structure allows easy installation in space-limited devices.
Design Standards
The module is built according to strict industrial-grade design standards, focusing on reliability, durability, and efficiency. The PCB layout is optimized to minimize electromagnetic interference and ensure stable signal integrity during continuous operation. High-quality materials are used in both the LCD panel and supporting components to enhance durability and extend service life. The mechanical design supports secure mounting and resistance to vibration, making it suitable for harsh working environments. Low power design principles are applied to reduce energy consumption and improve overall system efficiency, especially in continuous-use applications.
Applications
The Graphic LCD Display Modules are widely used in industrial automation systems, measurement instruments, medical devices, communication terminals, and smart control equipment. They are also commonly integrated into human-machine interface (HMI) panels, embedded controllers, and portable electronic devices. Their ability to deliver clear graphical and textual information makes them ideal for applications requiring reliable data visualization and intuitive user interaction in professional and industrial environments.
Product Size
FAQ
Q: Do you provide samples?
A: Yes, samples are typically available within 1-3 days for customers to test and evaluate the module's performance and compatibility.
Q: How to customize this LCD display module?
A: The module can be customized according to customer requirements, including character display content, backlight color, shell design, and other parameters, to meet specific application needs.
Q: What applications is this module suitable for?
A: This module is suitable for applications requiring the display of large font characters and numbers, such as meters, equipment control panels, and information display systems.
Q: How is the quality of this module?
A: This module is manufactured using high-quality LCD panels and electronic components, designed to be stable and reliable, ensuring long-term stable operation and high-quality display performance.
Q: How is cost-effectiveness ensured?
A: The module is designed with streamlined production and cost control, aiming to provide a cost-effective solution while maintaining high quality and performance.
If you would like to learn more or customize the LCD display screen you need, please feel free to contact us.
